^Lot 1038 Vintage Dynaco PAT-5 Solid-State Stereo Preamplifier Control Center with Phono Inputs

Dynaco PAT-5 solid-state stereo preamplifier and control center with a brushed metal faceplate and black chassis. Controls include six-position source selection, volume, balance, independent-channel bass and treble, A/B speaker switching, tape monitoring, stereo and mono selection, an external processor loop, low and high filters, tone-control defeat, headphone jack, and power switch. Rear connections include two phono inputs, tuner and spare inputs, two tape loops, external processor loop connections, dual stereo outputs, amplifier and two-pair speaker binding posts, a ground terminal, and four convenience outlets. The unit is configured for 120V AC operation.

Manufacturer: Dynaco
Model: PAT-5
Type: Solid-state stereo preamplifier and control center
Period: Mid-1970s
Power: 120V AC; manufacturer-rated consumption 12 watts
Manufacturer-Rated Frequency Response: High-level inputs: 10 Hz-50 kHz, ±1 dB
Published Model Dimensions: 13.5 in. W x 4.25 in. H x 11.75 in. D
Condition: As pictured.
